Introduction:
Our company has advanced technologies and techniques in order to produce the Q43P series Metal Crusher, which are combined with our present design and manufacturing skills. The crusher is driven by hydraulic system. The user can choose manual valve control and PLC control.
①Application: Manufactured by adopting advanced technology, our Q43P series of metal crushers can be used to crush not only scrap metal, but also waste papers, plastics, auto tires, straws, timbers, thin wall cans, etc.
②Simple maintenance: Small crusher is designed with integral structure type hobbing cutter. Medium size or large size crusher uses assembled type hobbing cutter and the damaged cutter can be replaced directly.
③This metal crusher is characterized by low rotating speed, low running noise, large torque, rational design.
④Long service life, low operating and maintenance cost, and so on.
| No. | Model | QTY and Width of blades | Power | Overall size | Weight |
|---|---|---|---|---|---|
| 1 | Q43P-500 | 32(15mm) | 7.5kW | 1130×1300×1100mm | 1.5t |
| 2 | Q43P-600 | 20(30mm) | 11kW | 2200×840×1600mm | 2.5t |
| 3 | Q43P-1000 | 33(30mm) | 2×22kW | 1800×3000×3500mm | 4.0t |
| 4 | Q43P-1300 | 43(30mm) | 2×30kW | 3400×1300×1300mm | 7.5t |
| 5 | Q43P-1500 | 30(50mm) | 4×30kW | 2000×1900×2800mm | 12t |
| 6 | Q43P-2000 | 26(75mm) | 4×55kW | 6500×2000×2800mm |
18t |
